A home jump course does not need a show-grounds budget. Two pairs of standards, a stack of poles and a set of cups will build a vertical, an oxer, a crossrail and every pole exercise you need to school a horse properly. What it does need is the right sizes and a few non-negotiable safety details, because a badly built fence at home is more dangerous than any fence at a show.
Here is what to buy or build, the dimensions that matter in feet and meters, how to make DIY standards and poles safely, and what to avoid.
What do you need to build horse jumps at home?
At minimum you need jump standards, poles and jump cups. With two pairs of standards and six to eight poles you can build a vertical, an oxer or a crossrail, and use the same poles for ground pole work.
| Item | Starter quantity | What it is for |
|---|---|---|
| Jump standards (wings optional) | 2 pairs, 4 pairs for two fences | The uprights that hold the cups and poles |
| Jump poles (rails) | 6 to 8 | Fence rails, ground lines and pole work |
| Jump cups | 2 per pole in use, plus spares | Hold each pole on the standard |
| Flat cups or safety cups | 1 pair per spread | Back rail of oxers, planks and gates |
| Fillers (optional) | 1 or 2 | Flower boxes, panels or a small wall |
How long are horse jump poles?
Most jump poles in the US are 10 to 12 feet (3.0 to 3.7 m) long, with 12 feet (3.7 m) the most common size for a full-width fence. Many poles in Europe run 3.5 to 4 m (11 ft 6 in to 13 ft 1 in). Shorter poles, around 8 feet (2.4 m), are handy for narrow fences and pole work in a small arena. Poles are usually around 4 inches (10 cm) in diameter.
Heavier poles are safer than very light ones. A pole with some weight stays in place on the ground, rolls less when a horse steps on it and makes the horse respect the fence, while a very light pole can bounce, shift or fly up when it is touched.
How tall are jump standards?
Most standards stand 5 to 6 feet (1.5 to 1.8 m) tall, with a row of holes or a slotted track down one face so the cups can be set at any height. That covers everything from a crossrail to a big schooling fence. Wing standards, which add a wide panel on the outside, look good and help steer a green horse, but plain standards are easier to move and store. Each standard needs a wide, stable base so it does not tip when a pole is knocked.
How do you build DIY jump standards?
A simple, sturdy wooden standard is an upright post on a wide base, drilled with holes at even spacing for the cup pins. Keep the design plain:
- Use a smooth, sound post around 5 to 6 feet (1.5 to 1.8 m) tall. A 4 by 4 inch post is a common choice.
- Fix it to a wide base with two cross feet, so it stands on its own on uneven ground.
- Drill holes for the cup pins at even spacing up the face, starting low enough for crossrails and ground lines.
- Sand every edge and corner round, and check that no screw heads, nails or bolt ends stick out.
- Paint or seal it in a light color so the horse can see it clearly.
Buy the jump cups rather than making them. Commercial cups are shaped so a pole sits securely but rolls out when hit, and that release is the most important safety feature on the whole fence.
How do you make horse jump poles?
Use straight, smooth, sound timber of an even diameter, around 4 inches (10 cm), cut to 10 to 12 feet (3.0 to 3.7 m). Round off both ends, sand out any splinters and check for cracks or knots that could snap. Paint them in bright, contrasting colors, with bands or stripes, so the horse can judge the fence. Store poles off the ground and out of standing water so they do not rot or warp.
What are the safety rules for home-made jumps?
The single most important rule is that every rail must be able to fall. A fence where the pole cannot come down is a fence a horse can fall over.
- Never tie, screw or wedge a pole in place. Poles sit in cups and nothing else.
- Use flat cups or safety cups on the back rail of every oxer. In US licensed jumper classes, FEI-approved safety cups are required on the back rail of every spread, including in the warm-up; the same logic applies at home.
- Remove empty cups from the standards. A metal cup left sticking out at knee height is a common cause of injuries to horses and riders.
- No sharp edges, protruding screws or broken timber. Walk the whole fence with your hands before you jump it.
- Avoid pallets, tires and anything a hoof can go through or get caught in. Improvised fillers are where most home-made jump injuries start.
- Put jumps on good footing. A safe fence on hard or slippery ground is still unsafe.
A home-made jump is only as safe as its cups. Buy good cups and build the rest.
What fences can you build with a starter set?
Two pairs of standards and six to eight poles give you most of what you need to school:
- Crossrail: two poles crossed between one pair of standards. The first fence for any horse and the start of every grid.
- Vertical: one or two poles stacked in one plane, with a ground line at the base.
- Oxer: both pairs of standards set one behind the other, with the back rail in flat or safety cups.
- A small grid: trot poles into a crossrail and a one-stride vertical, using the numbers in our gymnastic grid distances guide.
- Pole exercises: the same poles on the ground for trot and canter work. See our ground pole exercises guide for distances.
Add a third and fourth pair of standards and you can build a real line, two fences a measured distance apart, which is where schooling at home starts to look like a course.
How much space do you need for home jumps?
A single fence needs room for a straight approach and a safe landing, with several strides of space on each side. A line of two fences needs the full related distance plus approach and run-off room. A standard 20 by 40 m (66 by 131 ft) arena fits a small grid or a short line; a 20 by 60 m (66 by 197 ft) arena or larger gives room for a simple course. Our arena dimensions guide covers what fits in each size.
How does HorseGrid help you plan a home jump course?
HorseGrid Designer lets you plan the course before you build it. Set your arena to its real size, drag in the fences you actually own, and the app shows the stride count and distance for every line in feet or meters, so you know how many standards and poles a layout needs and whether it fits. Free to download on the App Store.
Common questions
How long should jump poles be?
Usually 10 to 12 feet (3.0 to 3.7 m), with 12 feet (3.7 m) the most common in the US. Many European poles run 3.5 to 4 m (11 ft 6 in to 13 ft 1 in).
How tall should jump standards be?
Most are 5 to 6 feet (1.5 to 1.8 m) tall, which is enough for everything from crossrails to a big schooling fence.
What are safety cups on horse jumps?
Safety cups hold the back rail of a spread and release it if a horse hits it hard from above, so the horse does not get trapped between the rails. They are required on the back rail of every spread in US licensed jumper classes.
Can you use PVC for horse jumps?
PVC standards and poles are light, cheap and weather-resistant, and many riders use them for ground poles and small fences. Very light poles can bounce or shift when touched, so check that they sit securely in the cups and stay put on the ground.
